24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

Ningbo Uv Light & Electricity Co., Ltd.
Contact Now
    Buy cheap 24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver from wholesalers

    Buy cheap 24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver from wholesalers
    • Buy cheap 24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver from wholesalers
    • Buy cheap 24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver from wholesalers
    • Buy cheap 24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver from wholesalers

    24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

    Ask Lasest Price
    Brand Name : UV, Yoway
    Model Number : PW15-425-18
    Certification : CE,ROSH
    Price : $6-$45/SET
    Payment Terms : T/T
    Supply Ability : 5000pcs per month
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

    24V DC Electronic UVC Lamp Ballast Sterilizer 18w 4 Pin For T5 ballast UVC lamp Driver

    PL15-425-18D24 input 12V 24V dc uv sterilizer lamp ballast 18w 4 pin uvc light electronic ballast

    Product Description

    The compatibility between UV germicidal lamps and ballasts is very important, but which is often ignored unfortunately during practical application.

    There are magnetic ballasts and electronic ballasts in the market, but the latter is more environmental than the former, saving energy. Lightbest can provide multiform electronic ballasts and inverters compatible with lamps.

    24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

    Product Display

    24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

    Output parameters PPW15-425-18
    Input voltage range Max 17W
    Input current 0.35-0.42A
    Voltage 230V
    Start time ≤ 8mS
    230V
    Use environment ta) - 5℃…+ 40℃

    Installation case:

    1.If the power of the ballast is less than the power of the lamp tube, the lamp emits less light, or even does not light up. 2.If the ballast power is greater than the lamp power, the lamp life will be reduced; the greater the power gap, the more life will be reduced. 3.In addition, the voltage of the ballast must match the power supply voltage.

    l Technical specifications

    Lamp Types:GPH212T5 GPH287T5 GPH303T5 GPH357T5 TUV11W TUV16W

    l Technical specifications

    Efficiency: >70%

    Operating Frequency: 40-70KHz

    Dimensions:85*43*27mm

    Max.cable length between ballasts and lamp:1.5m

    l Installation requirement

    Wire Gauge:0.5-1.0mm2

    LED specification:VF=1.8-3.6V LF=20-50mA

    l Mounting restrictions

    Disconnect Input Power Before Installing or Servicing.

    Ballast Case Must Be Grounded.

    Don’t short any two wires of the four outputs.

    Don’t short any two wires of the four outputs.

    l For applications with less than one switch-on cycle per day

    (other otherwise preheat start ballasts are recommended)

    Lamp filament must be suitable for instant start operation,ask lamp manufacturer.

    l Features

    Starting:Instant

    Lamp status indication via DC signal output.

    DC3~6V 5mA:lamp on. DC 0~0.8V:lamp fault or on lamp. Connect LED

    l Applications

    All areas of applications include Tanning UV lamps:

    =>Air purification

    =>Aquarium

    =>Domestic drinking water

    Type Input Voltage(V)

    Input Power

    (W)

    Input Current (A) Power Per Lamp(W) Lamp Current(A)

    Weight

    (kg)

    Packing

    (mm)

    Qty ( pcs ) GW (kg)
    PL15-180-10D24 21.4~26.4 5.7-11.5 0.48A@24V 4-8 0.16-0.18 0.15 450*280*190 100 15.5
    PL15-350-15D24 21.4~26.4 21.4 0.89A@24V 15 0.30-0.35 0.15 450*280*190 100 15.5
    PL15-425-18D24 21.4~26.4 14.3-24.3 1.0A@24V 10-17 0.35-0.42 0.15 450*280*190 100 15.5
    PL15-180-10D12 10.8~13.2 5.7-11.5 0.96A@12V 4-8 0.16-0.18 0.15 450*280*190 100 15.5
    PL15-350-15D12 10.8~13.2 21.4 1.78A@12V 15 0.30-0.35 0.15 450*280*190 100 15.5
    PL15-425-18D12 10.8~13.2 14.3-24.3 2.0A@12V 10-17 0.35-0.42 0.15 450*280*190 100 15.5

    Advantages:

    Short circuit limiting power consumption: output short circuit, no danger, fault removed, relevant parameters meet the requirements of the letter of acceptance

    1.9 open circuit limiting power consumption: the output is open circuit, without any danger, the fault is removed, and the relevant parameters meet the requirements of the acknowledgement

    1 KITCHEN FUME PURIFICATION
    2 DEODORIZATION AND PURIFICATION TREATMENT
    3 REMOVE ODOR AND PURIFIY INDUSTRIAL WASTE GAS

    24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver24V DC UV Sterilizer Ballast 18w 4 Pin For T5 Ballast UV Lamp Driver

    The Eight Core Technologies

    1.Core filament electronic power processing technology.
    2.Use the best quality raw materials----Glass tube UV transmittance>93%. 3.Unique inner coating film and outer coating film technology.
    4.Solid mercury----Homemade special mercury fixation to improve light efficiency.
    5.Unique patented rapid leak detection technology
    6.Unique wick anti-vibration patented technology .
    7.The most advanced automated processing equiment in China.
    8.Cost advantage and perfect pre-sales and after-sales service.

    Ningbo UV Light & Electricity Co.,Ltd is a professional manufacturer of ultraviolet germicidal lamp and related products, integrating R&D, production, sales together. UV germicidal lamp is our main product, incuding sing-ended, double ended, U shape, H shape, amalgam UV lamps, etc.

    FAQ

    Q: What's your advantage compared with other suppliers?

    A: Our UV lamps are made with high-quality quartz.CE and Rohs certificates and competitive prices.

    Q:What's my consideration when I choose one model of uv lamps?

    A: Watts,Length,Volt and current about the electric ballast.

    Q:What are the types of use of different UVC lamps?

    A:Different uvc lamps can be used for water treatment,aquarium,medicial care, air purification and so on.

    Q:What is the difference between normal and amalgam lamps?

    A:Compared with the normal lamps, Amalgam lamp increase the ultravaiolet output efficiency by 2-3 times at the same length.and it also can stand above 70°C .

    Q:How does the generated OZONE affect the health of people?

    A:Excessive ozone can cause human organ failure.

    Q:Can you accept the OEM or ODM?

    A: Yes.
